GeForce RTX 2060 SUPER DLSS 4.5 vs DLSS 5: setting the real question
The GeForce RTX 2060 SUPER officially supports DLSS 4.5 Super Resolution and Ray Reconstruction. NVIDIA has not announced DLSS 5 launch support for the card, and future support remains unknown.
For developers and players in 2026, the decision comes down to measured performance in current games and whether the existing DLSS path keeps the GPU useful. Three published results provide that baseline without pretending a newer version is available.
DLSS 4.5 is the supported feature set
NVIDIA launched the Turing-based RTX 20 family in late 2018 and 2019. It was the first consumer generation with dedicated RT cores for ray tracing and Tensor cores for AI inference. Those Tensor cores run DLSS, but Turing does not receive every mode advertised for RTX 40 or RTX 50 hardware.
On the GeForce RTX 2060 SUPER, DLSS 4.5 includes the Super Resolution upscaler and Ray Reconstruction denoiser. Games with either feature integrated can run it through the standard NVIDIA driver on the card’s Tensor cores. Newer additions from 2024 and 2025, including multi-frame generation, require the Optical Flow accelerator in Ada and Blackwell and do not run on this GPU regardless of driver version.
The RTX 20 series entry on English Wikipedia lists the family launch dates, Turing architecture, and RTX 2060 SUPER’s place in the range. That architecture, not a missing menu flag, is why some later features cannot run.
Super Resolution and Ray Reconstruction share Tensor resources
DLSS 4.5 Super Resolution takes a lower-resolution scene, processes it through a convolutional neural network trained against high-resolution references, and outputs one reconstructed frame for each input frame. Quality presets map to internal render scales, which developers must balance against frame time, memory bandwidth, and full-resolution post-processing.
Ray Reconstruction cleans noisy ray-traced reflections, global illumination, and shadows. On Turing, it uses the same Tensor cores as Super Resolution. A game running both in one frame therefore needs enough time for their combined neural workload.
DLSS still has a cost. The engine must create the render target, fill the network inputs, and dispatch inference. Geometry, shadows, and ray-traced passes may also run at different resolutions from the upscaler input. A deferred renderer needs explicit choices about which passes use render scale and which use output scale, especially when memory bandwidth is already tight.
DLSS 5 is not an official option on this card
No official DLSS 5 launch support has been announced for the GeForce RTX 2060 SUPER. NVIDIA has not promised future driver support either.
On Turing, the DLSS SDK exposes Super Resolution and Ray Reconstruction. Calls to newer DLSS 5 entry points may return a runtime error or fall back to the older path, depending on the integration. A game built around those newer features will not behave as designed on this GPU.
Players can still use games that retain DLSS 4.5. A title that ships only the new path may fail to enable upscaling or run below the intended quality. The card remains usable, but it is outside the latest feature set.
DLSS 5 uses a more complex neural network and assumes the Optical Flow accelerator, larger Tensor Core resources, and memory bandwidth of Ada or Blackwell. The RTX 2060 SUPER lacks that Optical Flow hardware, and software cannot replace a missing unit for features that depend on it.
Native 1080p results range from 4.9 to 61.8 FPS
The Notebookcheck RTX 2060 SUPER desktop benchmark page provides the three measurements below. They are the only FPS values used here; other performance descriptions remain relative.
| Game | Resolution | Settings | Average FPS | Notes |
|---|---|---|---|---|
| Cyberpunk 2077 1.6 | 1920×1080 | Ray Tracing Ultra Preset (DLSS off) | 22.5 | Direct Notebookcheck measurement, native render scale, DLSS disabled in this run. |
| Cyberpunk 2077 | 1920×1080 | 30 minute Start Ultra Preset (FSR off) | 61.8 | Direct Notebookcheck measurement, Ultra Preset at the start of the game, FSR disabled. |
| Alan Wake 2 | 1920×1080 | High Preset + High Ray Tracing | 4.9 | Direct Notebookcheck measurement, High Ray Tracing on, DLSS off in this run. |
The 22.5 FPS Cyberpunk 2077 1.6 run uses Ray Tracing Ultra at 1080p with DLSS off. The 61.8 FPS result uses the same engine, card, and resolution but the standard Ultra Preset at the start of the game with FSR disabled. Alan Wake 2 supplies the worst case with a much heavier fully ray-traced workload.
Cyberpunk 2077 is playable at its standard Ultra Preset but not at Ray Tracing Ultra on the same card and resolution. Alan Wake 2 at High Ray Tracing reaches only 4.9 FPS natively, making that figure a floor for a demanding fully ray-traced path rather than a design target.
The difference between 22.5 and 61.8 FPS comes from the presets, not an upscaler comparison. A ray-traced mode on this GPU will rely heavily on DLSS, and the reconstructed image still has to remain stable enough to ship.
DLSS 4.5 helps only when the base workload is viable
DLSS 4.5 lowers base-render cost through a reduced internal resolution, lets the denoiser consume a lower-resolution ray-traced input, and reconstructs a better final frame than a basic bilinear upscale. Those gains can make a workable 1080p ray-traced mode hold its target.
They cannot rescue every workload. Alan Wake 2’s 4.9 FPS result at 1080p with High Ray Tracing is too low for single-frame upscaling to make playable. A build targeting this card must reduce ray tracing, resolution, or both. Even a future DLSS 5 path would face the same limit because ray samples per pixel, not just upscaling, dominate the workload.
Developers should ship 4.5; players should choose presets carefully
A 2026 build retaining RTX 2060 SUPER support should use DLSS 4.5 as its primary path, handle newer entry-point errors or fallbacks, and document the expected behavior in QA. DLSS 5 support remains unknown.
Technical artists should tune render scale and ray-traced pass cost from the 22.5 FPS native Cyberpunk 2077 1.6 result. Around 50 percent of output resolution is a reasonable starting point for a Quality preset when the card is already near its limit, but the upscaler and denoiser must both fit the frame-time budget.
Players should focus on presets rather than version numbers. Standard Ultra in Cyberpunk 2077 is playable at 1080p, while Ray Tracing Ultra is not. DLSS 4.5 can support a sensible preset, but it cannot fix a fully ray-traced workload that starts too far below the target.
Upgrade when the target workload stops fitting
Alan Wake 2 at 4.9 FPS with High Ray Tracing shows that this card cannot support a fully ray-traced 1080p preset at a playable rate. A standard 1080p Ultra preset without full ray tracing remains a much better fit, and DLSS 4.5 can help stabilize it.
Developers who keep the GPU in their support list need a separate, honest preset. Projects requiring stable full ray tracing at 1080p should place the card below that preset’s minimum specification.
Players who mainly use standard 1080p settings can still get useful service from the card. Those prioritizing fully ray-traced 2026 games will need newer hardware. Base the upgrade on games that matter, not on uncertain DLSS 5 support.
The feature table is mostly a support check
On the GeForce RTX 2060 SUPER, DLSS 4.5 is available and DLSS 5 is not officially supported at launch:
| Feature | DLSS 4.5 on GeForce RTX 2060 SUPER | DLSS 5 on GeForce RTX 2060 SUPER |
|---|---|---|
| Super Resolution upscaler | Officially supported, runs on Turing Tensor cores. | Not officially supported at launch. Future support unknown. |
| Ray Reconstruction denoiser | Officially supported, runs on Turing Tensor cores. | Not officially supported at launch. Future support unknown. |
| Multi-frame generation | Not available. Needs Optical Flow accelerator. | Not available. Needs Optical Flow accelerator on Ada or Blackwell. |
| Quality presets (Performance, Balanced, Quality, Ultra Quality) | Available through the standard SDK. | Not available on this card at launch. |
| Runtime behavior when called | Runs the upscaler or denoiser on the card. | Either returns an error or falls back to the DLSS 4.5 path, depending on integration. |
| Hardware dependency | Turing Tensor cores. | Ada or Blackwell Tensor cores plus Optical Flow accelerator. |
The DLSS 5 column reflects the current support matrix, not a prediction about later drivers.
Verify support and performance before deciding
Run these checks before publishing a requirement or buying around one feature:
- Check NVIDIA driver notes and DLSS SDK documentation. The card supports DLSS 4.5 Super Resolution and Ray Reconstruction, with no official DLSS 5 launch announcement.
- Reproduce performance in the actual game or engine. The published measurements are references, not transferable results for another workload.
- Recheck official NVIDIA channels before quoting DLSS 5 status. State that future support is unknown instead of predicting the next driver.
These checks do not replace QA, but they prevent an unsupported public claim or purchase assumption.
Frequently asked questions
Does the GeForce RTX 2060 SUPER support DLSS 5?
No official launch support has been announced, and future support remains unknown. The card can run DLSS 4.5 Super Resolution and Ray Reconstruction on its Turing Tensor cores through the standard NVIDIA driver.
What is the difference between DLSS 4.5 and DLSS 5 in practice on a Turing card?
It is a support difference rather than a measured quality contest. DLSS 4.5 provides supported Super Resolution and Ray Reconstruction. DLSS 5 has no official launch support on the card.
Will a future driver add DLSS 5 support to the GeForce RTX 2060 SUPER?
NVIDIA has not announced it. Ship DLSS 4.5 as the primary path and treat any later DLSS 5 support as an optional update.
Is DLSS 4.5 useful on the GeForce RTX 2060 SUPER?
Yes, on workloads already within reach. Cyberpunk 2077 averages 61.8 FPS at standard Ultra and 22.5 FPS at Ray Tracing Ultra with DLSS off. DLSS can help stabilize a sensible preset, but it cannot make every fully ray-traced mode playable.
What frame rate can the GeForce RTX 2060 SUPER hold on Alan Wake 2?
Notebookcheck reports 4.9 FPS at 1920×1080 on the High Preset with High Ray Tracing and DLSS off. That workload is not playable on the card, and single-frame upscaling cannot close such a large gap.
Should a developer ship a DLSS 4.5 path or a DLSS 5 path for the GeForce RTX 2060 SUPER?
Ship DLSS 4.5. Newer entry points may fail or fall back on Turing, and the card has no official DLSS 5 launch support. Choose a quality preset that leaves the supported upscaler enough room to help.
Should a player upgrade from the GeForce RTX 2060 SUPER to run DLSS 5?
Upgrade when the card no longer holds a playable frame rate in the games you use. DLSS 5 support is unannounced and should not be the deciding factor by itself.
What render scale should a technical artist use for DLSS 4.5 on the GeForce RTX 2060 SUPER?
Around 50 percent of output resolution is a reasonable starting point for a Quality preset near the card’s limit. Engine design, full-resolution post-processing, and memory bandwidth can change the result, so profile the actual pass before locking it.
Where do the frame-rate numbers come from?
All three come from Notebookcheck’s public NVIDIA GeForce RTX 2060 Super desktop benchmarks and specs page. They are reproduced as published, and no other FPS values are introduced.
What is the right next step for a project that targets the GeForce RTX 2060 SUPER?
Confirm the matrix in NVIDIA’s driver and SDK notes, reproduce performance in the shipping engine, and lock DLSS 4.5 as the primary path. Keep DLSS 5 out of scope until NVIDIA announces support for the card.
